FMT 230V-100lpm Diesel Transfer Vane Pump

FMT 230V-100lpm Diesel Pump

FMT 230V-100lpm Diesel Transfer Vane Pump

£269.60 £323.52

In stock
FEATURES OF THE FMT 230V, 100LPM FUEL TRANSFER PUMP:
  • Connecting cable – Length: 2m
  • Connection inlet/outlet – 1” female
  • Pump design – vane pump, self priming
  • Flow rate – 100lpm
  • Max Pressure – 2.2 Bar
  • Suction height – 5m
  • Voltage – 230v

£269.60 £323.52

SKU: P-23-433

Description

FMT 230V-100lpm Diesel Pump

A top quality, Swiss-made sliding-vane pump, designed for use with diesel and other products which are not aggressive to the pumps component materials. Due to their unsurpassed reliability on continuous duty operations, these can also be used as process pumps.


  • First class construction of electric machines and pumps
  • Designed for a long service life
  • Encapsulation of the electric motor, which, in case of extreme temperature fluctuations, largely prevents the formation of condensed water and of short-circuits resulting thereof
  • Motor and switch case made of shock resistant, die-cast aluminium
  • Continuous operation – a real endurance runner
  • Suction height: 5m
  • Small tolerances provide a high suction- and pressure performance
  • Pump case freely positional in all 90° positions
  • Vane pump, with integral bypass
  • On/Off switch
  • Siphon protection acc. to WHG (German government regulation for environmental care), continuously active

Connecting cable, length (m) 2
Connection suction side G 1” female
Connection discharge side G 1” female

Hydraulic data
Pumping media fuel oil and diesel
Pump design vane pump, selfpriming
Delivery rate under free discharge (l/min) / US gal 100 / 26,4
Suction height (m) 5
Discharge pressure up to (bar) 2,2

Motor data
Insulation class F
Highest permissible limit temperature (°C) 155
Voltage (V) 230
Frequency (Hz) 50
Power consumption (A) 5,7
Power (kW) 1,2
Thermal protection self resetting
Duty cycle (min) Continuous operation – a real endurance runner
Torque (Nm) 4,1
Rotation speed (rpm) 1400
Type of construction IMB 3
Safety class IP54

Materials of parts in contact with liquid
Seals FKM (Viton®)/NBR
Pump housing AlSi 12 (sea water resistant)
Rotor GG 25
Vane POM

Dimensions LxWxH (mm) 320 x 135 x 190
Weight (kg) 10,08

As well as this FMT 230V-100lpm Diesel Pump we supply the complete range of FMT Diesel transfer pumps at Fueldump, please see here – FMT Diesel Transfer Pumps

This pump comes with a 2 pin euro plug, if you are not wiring this pump in directly then we do offer the commando caravan style plugs and sockets – Commando Plug, Commando Socket

Additional information

Weight2 kg
Flow Rate

91-120lpm

Fluid Type

Diesel

Product Type

Pump
