PIUSI NEXT/2 OIL FLOW METER
NEXT/2 is an oval gear electronic flow meters in acetal resin for controlling non-commercial dispensing of low, medium and high viscosity fluids including Lubricating oils and other special fluids compatible with construction materials.
- Body with aluminium measuring chamber.
- 5-digit partial total (h=11.5 mm) with floating point from 0.001 to 999.99
- 8-digit non-resettable total (h=5 mm) from 1 to 99999999.
- Resettable total.
- Repeatability 0.2%
- Loss of pressure <0.5 bar at maximum flow rate
- Flow rate up to 60 l/min
- Accuracy +/- 0.5%
- Maximum operating pressure 70 bar
- Bursting pressure: 140 bar
