FMT Digital Oval Gear Flow Meter

FMT Digital Oval Gear Flow Meter

FMT Digital Oval Gear Flow Meter

£95.00 £114.00

In stock
  • Easy to read 5-digits display
  • Connection G 1” female
  • Flow capacity 2- 100lpm
  • Measuring accuracy (%) 0,5
  • Nominal Pressure 3.5bar
  • Resettable Display

£95.00 £114.00

SKU: P-23-190


FMT Digital Oval Gear Flow Meter
The FMT Digital Oval Gear Fuel flow meter is a 1″ ported meter for measuring dispensed diesel, complete with a 5 digit batch display. Accurate to 0.5%
  • Totalisator for daily operation 5-digits with floating decimal, resettable to zero, partition 0,000 up to 99999
  • Totalisator 6 digits with floating decimal, partition 0,0 up to 999999
Special notes
  • Easy to read 5-digits display
  • Resettable display
  • The metering precision can be adjusted to the viscosity using the calibration scale
  • The user can adjust the following indicating units: Litres, gallons, pints, quarts
  • Displays: Indication of partial quantity equals current filling level (resettable to zero) + total quantity (resettable to zero) + total quantity (not resettable to zero)
  • Distance in-/out flange (mm) 95
  • Connection G 1” female
  • Media diesel, fuel oil, self lubricating low viscosity liquids
  • Flow capacity min. (l/min) 2
  • Flow capacity max. (l/min) 100
  • Pre-set flow direction horizontal
  • Permitted liquid temperature max. (°C) 40
  • Permitted ambient temperature (°C) -10 / +60
  • Measuring accuracy (%) 0,5
  • Nominal pressure (bar) 3,5
  • Burst pressure (bar) 28
  • Battery lifetime approx. 2 years at 0.5 hours per day (20 °C)
  • Materials of parts in contact with liquid
  • Meter housing AlSi 12 (sea water resistant)
  • Oval gears POM
  • Seals NBR 70
  • External dimensions LWH (mm) 100 x 100 x 65
  • Weight (kg) 0,58

Dimensions LxWxH (mm) 145 x 126 x 78
Weight including package (kg) 0,67
Packing unit 1,0

As well as this FMT Digital Oval Gear Flow Meter we also supply an FMT digital turbine meter and a mechanical Oval gear meter from FMT – please see products below.

The full range of FMT products we supply can be found here – FMT refuelling products
